TB50 LED Media Player

TB50 LED Media Player: a NovaStar controller for LED walls up to 1,300,000 pixels. It offers 4K@60Hz decoding, HDMI input and output, dual Gigabit Ethernet with main and backup and Android 11, powered directly from AC mains. Built for large commercial installations.

Category:
Maximum pixel capacity icon

1,300,000 px

Max pixel capacity

Video decoding icon

4K@60Hz

Video decoding

Operating system icon

HDMI in/out

Input and output

Ingress protection icon

IP20

Ingress protection

In. Out.
Both ways.

Take a live HDMI feed in and send a preview out to a monitor on site.

TB50 LED Media Player controller for LED walls, front and rear panels

Technical specifications

All the details for your project.

Performance

Value

Hardware & power

Value

Processor

ARM Cortex-A55 quad-core, 1.8GHz

Sync methods

NTP, GPS (4G module), RF (RF module)

RAM / Storage

1 GB / 32 GB

Dimensions

274.3 × 139.0 × 40.0 mm

Max pixel capacity

1,300,000 px

Weight

1234 g

Max resolution

4096×4096 px

Power input

AC 100–240V, 50/60Hz, 0.6A

Video decoding

H.264/H.265, 4K@60Hz

Max power consumption

18 W (25 W PSU recommended)

Connectivity

2×GbE (primary/backup), HDMI in + HDMI out, USB 3.0, USB-B, Wi-Fi AP+Station

Environmental sensors

2× connectors (brightness / temp / humidity)

Operating system

Android 11.0

Ingress protection

IP20 (indoor use)

TB50 LED Media Player for LED Walls Up to 1,300,000 Pixels

The TB50 LED Media Player is a NovaStar controller that plays and manages content on LED displays and LED walls of up to 1,300,000 pixels, the highest pixel capacity in the TB series. It decodes H.264/H.265 video at 4K@60Hz, adds an HDMI input and an HDMI output, and offers dual Gigabit Ethernet.

It is built for large commercial and smart city installations. The two Gigabit Ethernet ports run as a main link and a live backup, or as two independent outputs. The HDMI output feeds a monitor on site, so staff can confirm what the LED wall is showing. Power comes directly from 100 to 240V AC.

TB50 LED Media Player controller for LED walls, front and rear panels

Key benefits of the TB50 LED Media Player

HDMI input and output

Take a live HDMI feed in for synchronous mode, and send an HDMI output of up to 1920×1200@60Hz to a preview monitor.

1,300,000 pixel capacity

Double the pixel capacity of the TB30, driving the largest LED walls in the range from a single unit, at up to 4096×4096 px resolution.

Configurable dual Ethernet

The two Gigabit Ethernet ports can run as two independent outputs or as a main and backup pair for automatic failover. The installer chooses the configuration on site.

Environmental sensor inputs

Two dedicated connectors accept brightness or temperature and humidity sensors, so the display can adjust to real ambient conditions.

Direct AC mains power

It accepts 100 to 240V AC directly, at up to 18W (a 25W power source is recommended), with no separate DC adapter to source or replace.

Applications for the TB50 LED Media Player

Fixed commercial displays

The highest pixel capacity in the TB series drives the largest fixed commercial LED walls from a single controller, with dual Ethernet keeping content live.

Retail chains and point of sale

The HDMI output lets on-site staff monitor exactly what is shown on shelf and point-of-sale displays, without separate confirmation hardware.

Advertising and signage

1.3 million pixels of capacity and 4K@60Hz decoding handle large-format advertising players and commercial signage without dropped frames.

Smart city and street displays

Sensor inputs let street pole and smart city displays adjust automatically to real ambient conditions.

Certification and support

The TB50 LED Media Player is CE and RoHS certified for sale and use in the EU. It comes with a standard 2-year warranty, extendable to 5 years, and technical support managed directly from Italy. Compare it with the TB10 Plus, TB20 Plus, TB30 and TB60, or request information for your project.

TB50 LED Media Player FAQ

How does the TB50 differ from the TB30?

The TB50 has a maximum pixel capacity of 1,300,000, double the 650,000 of the TB30, plus an HDMI input and an HDMI output, which the TB30 does not have. Processor, RAM, dimensions and dual Ethernet are otherwise the same.

What is the HDMI output used for?

It sends the same signal that goes to the LED display (up to 1920×1200@60Hz) to a standard monitor, so on-site staff can confirm what is shown without walking up to the wall.

Can the two Ethernet ports be used independently?

Yes. The two Gigabit Ethernet ports can be configured as two separate outputs or as a main and backup pair for automatic failover, depending on the installation.

What sensors can be connected to the TB50?

Brightness and temperature/humidity sensors. Two dedicated connectors accept them, allowing the display to adjust automatically to real ambient conditions.

What multi-screen synchronization methods are supported?

Three: NTP over a standard internet connection, GPS sync (via an optional 4G module) and RF sync (via a dedicated RF module).

Is the TB50 suitable for outdoor installations?

Not on its own: it is rated IP20, for indoor use only. For outdoor deployments, house the unit in a sealed, weatherproof enclosure rated for outdoor use.

What certification, warranty and support does the TB50 include?

The TB50 is CE and RoHS certified for sale and use within the EU. It has a standard 2-year warranty, extendable to 5 years, with technical support managed directly from Italy.

What are the power requirements for the TB50?

AC 100 to 240V, 50/60Hz, with a maximum draw of 18W (a 25W-rated power source is recommended). No external DC adapter is required.

What is the maximum pixel capacity and resolution of the TB50?

Up to 1,300,000 pixels per unit, with a maximum resolution of 4096×4096 px.

What does the HDMI input do?

It takes a live HDMI feed for synchronous mode, so live content can be shown on the LED display.
