Poster LED Display

Poster LED Display is a modular, wheeled indoor LED poster in P1.8, P2 and P2.5, with 600 to 800 nits brightness, a 3,840 to 7,680 Hz refresh rate and an optional GOB version.

Request information

Download datasheet

Category: Indoor LED Display

P1.8–P2.5

Pixel pitch range

3,840–7,680 Hz

Refresh rate

IP30

Indoor protection

600–800 nits

Brightness

Built to move.
Three pixel pitches.

Poster LED Display: modular indoor LED posters on a wheeled base, in SMD or GOB version.

Technical specifications

All the details for your project.

Optical & electrical	Value	Physical & environment	Value
Pixel pitch	P1.8, P2, P2.5	Mounting	Mobile base with silent industrial wheels and locking system
Versions	SMD and GOB (protective epoxy coating), on request	Module connection	Metal clips with safety clips, quick assembly without special tools
Brightness	600–800 nits	Configuration	Modular and scalable, from small displays to large video walls
Refresh rate	3,840–7,680 Hz	Cabling	Integrated, with hidden connections
Protection	IP30: indoor use, protected against dust and small objects	Maintenance	Single modules can be replaced without dismantling the structure
Structure	Ultra-light modular aluminium, anodised aluminium frame	Connectivity	LAN RJ45, Wi-Fi and USB
LED panels	High-density SMD technology	Installation	Indoor
Cooling	Natural convection	Certifications	CE, RoHS

Modular Indoor LED Posters for Retail, Museums and Events: P1.8, P2 and P2.5

Poster LED Display is a modular indoor LED poster for digital signage, built from rectangular panels that assemble into a video wall on a wheeled base. It comes in three pixel pitches, P1.8, P2 and P2.5, with 600 to 800 nits brightness, and it can also be offered in a GOB version.

This display is designed to be moved. Its ultra-light aluminium structure sits on a mobile base with silent industrial wheels and a locking system, so a whole configuration can be rolled to a new position without dismantling it. Modules stack into a uniform surface with integrated, hidden cabling, connect with metal clips and safety clips, and can be assembled in minutes without special tools, so the display can grow in steps from a small poster to a large video wall. Content reaches the display over LAN RJ45 for fixed installations, Wi-Fi for temporary ones, or USB for quick updates and stand-alone use.

Pixel pitch comparison

Brightness, protection and best use for each pixel pitch.

Pixel pitch	P1.8	P2	P2.5
Brightness	600–800 nits	600–800 nits	600–800 nits
Refresh rate	3,840–7,680 Hz	3,840–7,680 Hz	3,840–7,680 Hz
Protection	IP30, indoor	IP30, indoor	IP30, indoor
Versions	SMD or GOB	SMD or GOB	SMD or GOB
Best use	Maximum image definition, for audiences close to the screen	Best balance of image quality and cost, for most commercial uses	Medium to large installations, where visibility is needed from a greater distance

Key benefits of the Poster LED Display

Easy to move

A mobile base with silent industrial wheels and a locking system lets you reposition the whole display without dismantling it.

Quick assembly

Metal clips with safety clips join the modules in a few minutes, with no special tools.

Simple maintenance

A single module can be replaced without dismantling the rest of the structure.

Flexible content delivery

LAN RJ45 for fixed installations, Wi-Fi for temporary ones and USB for quick updates and stand-alone use.

Three pitches and a GOB option

P1.8, P2 and P2.5 cover close and far viewing, and the GOB version adds a protective epoxy coating for busier spaces.

Applications for the Poster LED Display

Retail and shop windows

Product launches, promotions and window displays that can be moved and changed with the season.

Museums and art galleries

Exhibition information and visual content in a slim, movable format.

Shopping centres and public spaces

Wayfinding, advertising and information points; the GOB version suits areas with heavy foot traffic.

Trade fairs and exhibitions

Stand displays that are set up quickly, rolled into place and moved between events.

Certification and support

Poster LED Display is CE and RoHS certified for sale and use in the EU. Technical support is managed directly from Italy. To manage the content, see the LED media players, or request information for your project.

Poster LED Display FAQ

What is the Poster LED Display?

It is a modular indoor LED poster for digital signage, assembled from rectangular panels on a wheeled base. It comes in P1.8, P2 and P2.5, with 600 to 800 nits brightness and IP30 protection, and it is CE and RoHS certified.

Which pixel pitches does the Poster LED Display come in?

Three: P1.8, P2 and P2.5. P1.8 gives the highest image definition, P2 balances quality and cost, and P2.5 suits larger installations where the audience is farther away.

Is the Poster LED Display available in a GOB version?

Yes. It can also be offered in GOB (Glue-on-Board) version, which adds a protective epoxy coating over the LEDs. This improves resistance to scratches and impact, and it suits public areas and high-traffic spaces. Request information to confirm the pitch you need.

How bright is the Poster LED Display?

Brightness is 600 to 800 nits, calibrated for indoor use, so content stays visible even under the strong lighting of shopping centres, showrooms and exhibition halls.

What IP rating does the Poster LED Display have?

It is rated IP30: protected against dust and small objects, and designed for indoor use only. It is not suitable for outdoor installation.

What is the size of the Poster LED Display?

The display is modular, so its overall size depends on how many modules you assemble, from a small poster to a large video wall, and the cabinet configuration is defined for each project. Request information with the space you have and our team will propose the right configuration.

How is the Poster LED Display moved and assembled?

The structure sits on a mobile base with silent industrial wheels and a locking system. Modules connect with metal clips and safety clips in a few minutes, with no special tools, so the whole display can be rolled to a new position without dismantling it.

How is the Poster LED Display maintained?

A single module can be replaced without dismantling the whole structure, and updates can be made without taking the display apart. Natural convection cooling keeps the temperature stable without fans.

How do I send content to the Poster LED Display?

Three ways: LAN RJ45 for fixed installations with a stable wired connection, Wi-Fi for temporary installations, and USB for quick content updates and stand-alone use.

How do I choose between P1.8, P2 and P2.5 on the Poster LED Display?

Choose from the viewing distance: P1.8 for audiences close to the screen, P2 for most commercial uses, and P2.5 for medium to large installations seen from farther away. Add GOB if the display will be in a busy public area. Request information and our team will recommend the configuration.
